With more than 40 years of designing and building bicycles and components dedicated to adventures that go beyond limits or expectations, Tom created the Ritchey WCS Adventure Gravel Fork for those of us who are unbound by: riding surface, seemingly insurmountable distances, or by what can be carried on your bike.

This one-piece carbon monocoque WCS Gravel Adventure Fork has been meticulously engineered and painstakingly built to perform with razor-sharp accuracy, deliver a high level of comfort and offer practical features for all manner of cycling adventures. Built with High Modulus Fiber (HMF), this impeccable adventure fork offers superior strength while also reducing road chatter fatigue on those endless days and nights in the saddle. Smooth internal fiber flow in the crown/steerer area delivers the best force transfer from the crown to the shaft and offers increased impact strength for those potholes you didn't see.

With your desire to ride far and long in any condition or under any circumstances, the WCS Adventure Gravel Fork features rack mounts for packs full of gear and fender mounts to keep the grime off you and your bike. Three multi-purpose mounts on the fork legs give you more places to stow necessities.

The WCS Adventure Gravel Fork also fits up to 48mm tires (depending on tire make and model), thus making this fork the ultimate addition to any rig assembled for the purpose of seeking, discovering and enjoying the adventure.

  • Multipurpose mounts on fork legs
  • Rack and fender mounts
  • Internal dynamo routing
  • Dynamo light mount
  • Compatible with 140 or 160mm disc brake rotors

TECHNICAL SPECS

  • Material:  carbon fiber
  • Steerer:  1-1/8" straight with integrated 45° crown race
  • Axle-crown:  393mm
  • Rake/Offset:  50mm
  • Crown Diameter:  47mm
  • Steerer length:  300mm
  • Spacing:  60mm
  • Axle Compatibility:  100x12mm thru-axle (included) – 15mm conversion kit available separately
  • Wheel and tire compatibility:  700 x 52mm, 650b x 2.0" (depending on tire/rim manufacturer)
  • Minimum Tire Clearance:  4mm road / 6mm offroad
  • Disc brake rotor compatibility:  140 / 160mm
  • Fork max load:  3kg per side
  • Weight:  445g (with uncut steerer / not including axle)
  • Color:  matte UD carbon finish
  • Flat Mount disc brake
  • Rack and fender mounts
  • Multipurpose mounts on fork blades (includes black stainless-steel bolts)
  • Dynamo light mount
  • Internal dynamo routing
  • Fits 1-1/8" headtubes with appropriate EC or IS headset
  • Fits 44mm headtubes when used with WCS ZS44/30 Lower 33055337010, or Comp Cartridge ZS44/30 Lower 33035337006
  • Incompatible with Comp Cartridge EC, Classic EC, EC Threadless and RL1 Ritchey headsets
  • 30mm maximum spacers below stem
